Lantronix EDS4100 User Manual

2: Introduction
EDS4100 4 Port Device Server User Guide 19
Technical Specifications
Table 2-1. EDS4100 Specifications
CPU
Intel
®
XScale IXP420 Network Processor running at 266MHz
32k Instruction Cache
32k Data Cache
Flash
8 MBytes Flash
RAM
32 MBytes SDRAM
EEPROM
2 KB
Firmware
Upgradable via the Web Manager, TFTP, or FTP
Serial Interface
4 DB9M serial ports: 2 RS232, 2 RS232/422/485, software selectable
Software-selectable standard baud rates from 300 to 230k baud.
Customizable baud rate support for non-standard serial speeds.
Serial Line Formats
Data bits: 7 or 8
Stop bits: 1 or 2
Parity: odd, even, none
Modem Control
CTS, RTS, DTR, DCD
Flow Control
XON/XOFF (software), CTS/RTS (hardware), None
Power Input
9-30VDC - Barrel connector
42-56VDC - Screw Terminal
PoE compliant power source - 802.3af (when populated)
Network Interface
RJ45 Ethernet 10Base-T or 100Base-TX (auto-sensing and hard
coded, auto-crossover)
Compliance
Ethernet: Version 2.0/IEEE 802.3 (electrical)
Ethernet II frame type
IEEE 802.3af (when PoE is populated)
Dimensions
Height: 12.7 cm (5.0 in)
Width: Without mounting brackets 17.65 cm (6.95 in)
Width: With mounting brackets 20.14 cm (7.93 in)
Depth: 3.81 cm (1.5 in)
Weight
.86 Kg (1.9 lb)
Temperature
0 to +55C operating temperature
-40 to +70C storage temperature
Relative Humidity
10 to 90%, non-condensing
