HVM200 Reference Manual Making the Measurement 3-8
3.3.3 Start/Stop the Measurement
Start Measurement
TRY THIS You can also start the
measurement manually by pushing
the power button on the HVM200 for
at least one second after it is stable
(or after the Status LED is red), see
“Power Button Operation” on
page 2-3.
Click the Run button that appears on the HVM200 Control app or G4 LD
Utility.
FIGURE 3-10 Meter is stopped
Stop Measurement
Click the Stop button.
FIGURE 3-11 Meter is running measurement
View Live Data
While meter is stopped and not taking a measurement, click the red Stop
button. A green Live button will appear. To return to stop, press Live
again.
FIGURE 3-12 Viewing Live Data & Meter is stopped
Observe Data
The HVM200 Control app provides the following data displays:
TRY THIS Alternatively, you can
also schedule measurements auto-
matically on the Schedule tab if you
do not need to observe them.
•Overall
• Summation
• X-axis
• Y-axis
• Z-axis
To advance from one data display to the next, click the Next Arrow. To
enlarge a data display, click the Zoom button.
