HVM200 Reference Manual 1/1 & 1/3 Octave Band Filters A-33
1/1 OBA 16.0 Hz Filter Response: Pass-band
1/3 OBA Filter Responses
1/3 Octave Filter Measurement Range
Frequency (Hz) Noise Floor (mV) Lower Limit Linearity (mV) Overload (V)
0.4 0.0064 0.071 5.01
0.5 0.0055 0.063 5.01
0.63 0.0057 0.112 5.01
0.8 0.0053 0.089 5.01
1 0.0052 0.126 5.01
1.25 0.0054 0.178 5.01
1.6 0.0050 0.079 5.01
2 0.0055 0.158 5.01
2.5 0.0055 0.178 5.01
3.15 0.0053 0.282 5.01
4 0.0050 0.141 5.01
5 0.0053 0.112 5.01
6.3 0.0054 0.200 5.01
8 0.0053 0.089 5.01
10 0.0053 0.089 5.01
12.5 0.0054 0.056 5.01
16 0.0053 0.056 5.01
20 0.0054 0.089 5.01
25 0.0055 0.071 5.01
31.5 0.0056 0.063 5.01
40 0.0057 0.089 5.01
50 0.0059 0.056 5.01
63 0.0062 0.056 5.01
