6 Specifications
CUTTING HEAD
Power Rating ............................................................................................................ 4 kW CW, 10 kW Peak
Focusing Lens (Effective Focal Length) ............................................. 100 mm, 125 mm, 150 mm, 200 mm
Focusing Lens (Diameter) ................................................................................................................. 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Assist Gas Pressure ............................................................................................................... up to 20 BAR
Purge Gas ........................................................................................................ 0.2 – 0.3 Bar (3.0 – 5.0 psi)
Air Cooling Pressure .................................................................................... 2.1 – 3.4 Bar (30.0 – 50.0 psi)
Water Pressure ................................................................................................ 5.0 Bar Max (72.5 psi max)
Water Flow ................................................................................................................................ 1.6 L/minute
Focal Point to Nozzle Adjustment ...................................................................................... -4 mm to +9 mm
Weight ...................................................................................................................................... 1.5 to 4.0 kg
LASER MECH COLLIMATOR
Effective Focal Length (Doublet, Fused Silica) ....................................... 35 mm, 60 mm, 75 mm, 100 mm
Collimating Lens (Diameter).............................................................................................................. 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Fiber Socket (Others Available On Request) ......................................................................... QBH, Q5, QD
HEIGHT SENSOR
Standoff Distance Range (1 mm recommended)............................................................ 0.2 mm to 8.0 mm
Calibration .......................................................................................................... Auto Calibrating at 12 mm
Response Time .............................................................................................................................. <1 msec
Temperature Stability .......................................................................... ±5% of Standoff Setting, 0° to 45°C
Power Requirement ...................................................................................................................... +24 VDC
Output .................................................................................................................................... 0-10 V Analog
See Interface Signals .................................................................................................................. Section 3.4
Specifications are subject to change without notice.
