7 Recommended User-Serviceable Parts List
For recommended user-serviceable spare parts, please call Laser Mechanisms at (248) 474-9480. If your head
requires service beyond the instructions outlined in this manual, please contact Laser Mechanisms for further
assistance.
ITEM
PART #
DESCRIPTION
ALL VISION AND FIBER OPTIONS
ELECTRICAL INTERFACE
1
PLCAB0489
14-Pin Cable (Used with Height Sensing Option)
2
PLHSU0073
Height Sensing Unit
3
PLGSK0002
Flat Gasket
4
PLTTW0003
Tip Transformer Wire (Used with Height Sensing Option)
5
PLCOV0005
Cover (Used with Non-Height Sensing Applications)
ADAPTER PLATE
6
PLFTG0128
Water Fitting (Included in PLADP0271)
ADJUSTABLE LENS HOLDER
7
PLMOR0032
Engagement O-Ring
8
PLFTG0128
Gas Fitting (Included in PLADP0194)
9
PLLRN0036
Lens Holder Retainer Nut
10
PLYFS0012
Lens 100 mm BFL
11
PLYFS0016
Lens 125 mm BFL
12
PLYFS0013
Lens 150 mm BFL
13
PLYFS0007
Lens 200 mm BFL
14
PLLSR0002
Lens Seal Ring
ADJUSTABLE LENS HOLDER SPACER
15
PLSBA0261
Adjustable Lens Holder Spacer for 125 mm BFL
16
PLMOR0030
Small Gas Seal O-Ring (Included in PLSBA0261)
17
PLMOR0031
Engagement O-Ring (Included in PLSBA0261)
18
PLSBA0262
Adjustable Lens Holder Spacer for 150 or 200 mm BFL
LENS MANIFOLD BLOCK
19
PLMOR0033
Large Gas Seal O-Ring (Included in PLLMB0132)
16
PLMOR0030
Small Gas Seal O-Ring (Included in PLLMB0132)
17
PLMOR0031
Engagement O-Ring (Included in PLLMB0132)
20
PLFLH0409
Cover Slide Drawer (Included in PLLMB0132)
21
PLLCG0034
Cover Slide (Included in PLLMB0132)
22
PLMSR0017
Manifold Seal Ring
LENS MANIFOLD BLOCK ASSEMBLY SPACER
23
PLSBA0268
Tip Retainer Assembly Spacer Block 100 or 125 mm BFL
24
PLORG0039
Gas Seal O-Ring (Included in PLSBA0268)
25
PLORG0040
Engagement O-Ring (Included in PLSBA0268)
26
PLSBA0269
Tip Retainer Assembly Spacer Block 150 mm BFL
27
PLSBA0270
Tip Retainer Assembly Spacer Block 200 mm BFL
