PLMNL0243 REV. A, Effective Date: 03/24/16 43 FiberMINI ™ 2.0 Operation Manual
ALL VISION AND FIBER OPTIONS
STANDARD TIP RETAINER ASSEMBLY – HEIGHT SENSING
Gas Seal O-Ring (Included in PLTRA0449)
Engagement O-Ring (Included in PLTRA0449)
Tip Retainer Assembly (Complete Height Sensing Assembly)
Tip Retainer Nut Assembly (Included in PLTRA0449)
STANDARD TIP RETAINER ASSEMBLY – NON-HEIGHT SENSING
Engagement O-Ring (Included in PLTRE0331)
Tip Retainer Assembly (Complete Non-Height Sensing Assembly)
Tip Retainer Nut Assembly (Included in PLTRE0331)
STANDARD NOZZLES (Consult with Laser Mechanisms RPS for a variety of tip sizes and types)
1.0 mm Orifice without Insert
1.5 mm Orifice without Insert
2.0 mm Orifice without Insert
Engagement O-Ring (Included in PLTRE0338)
Engagement O-Ring (Included in PLAKA0041)
OPTIONAL RIGHT ANGLE VISION
38.1 mm Diameter Laser Mirror (Included in PLOLV0046)
Mirror Retainer Spring (Included in PLOLV0046)
Mirror Retainer Screw (Included in PLOLV0046)
Mirror Retainer Spring (Included in PLOLV0047)
Mirror Retainer Screw (Included in PLOLV0047)
1.5 Inch Diameter Laser Mirror (Included in PLOLV0045)
Mirror Retainer Spring (Included in PLOLV0045)
Mirror Retainer Screw (Included in PLOLV0045)
1.5 Inch Diameter Laser Mirror (Included in PLOLV0045)
OPTIONAL RIGHT ANGLE FIBER INPUT WITH NO VISION
Mirror Retainer Spring (Included in PLOLV0045)
Mirror Retainer Screw (Included in PLOLV0045)
1.5 Inch Diameter Laser Mirror (Included in PLOLV0045)
