T
o remove the piston, lever with a screwdriver on the
rod to disengage it.
When the pin is disengaged press it with a finger to
remove it from its position.
Extract the piston from the top.
60
Manual code 10083445 / Rel. 0.00 / April 2010
Maintenance manual for technical assistance LB 2300-2301-2302-2311-2312
