CS3E-E Series EtherCAT Closed Loop stepper drive User Manual
49
201A
02
Closed loop holding
current percentage
R/W/S
UINT
0-100
50
%
Multiply by the value of object
0x2000, the drive output current
will change between these
according to the load.
201B
00
Locking duration
time
R/W/S
UINT
0-1500
200
ms
Appropriately reduce this value if
you want to shorten the time of
locking shaft.
201C
00
Max time to close
brake
R/W/S
UINT
100-10000
1000
ms
Usually keep the default value
201D
00
Zero speed point
R/W/S
UINT
0-500
10
0.1r/s
-
2024
00
Control Mode
R/W/S
UINT
0~10
2
--
0: Open Loop Control;
2: Closed Loop Control
2025
01
Speed point for
open loop
switching closed
loop
R/W/S
UINT
0~200
18
0.1r/s
-
2025
02
Delay for open loop
switching closed
loop
R/W/S
UINT
0~32767
12
ms
-
2025
03
Speed point for
closed loop
switching open
loop
R/W/S
UINT
0~200
5
0.1r/s
-
2025
04
Delay for closed
loop switching
open loop
R/W/S
UINT
0~32767
250
ms
-
2025
05
Feedback speed
point for closed
loop switching
open loop
R/W/S
UINT
0~200
50
0.1r/s
-
2029
00
Encoder resolution
R/W/S
UINT
4000-20000
4000
Coun
t
4 times the encoder resolution.
But it is recommended to modify by
0x608F+01
2030
00
Allowed max
position following
error pulses
R/W/S
UINT
0~32767
4000
Coun
t
4000 indicates the error of one
turn
2032
00
Distance to send "In
Position" output
signal
R/W/S
UINT
0-1000
4
Pulse
-
2033
00
Delay of in-position
error de-jitter
R/W/S
UINT
0-1000
3
ms
-
2047
00
Over voltage point
R
UINT
0-1000
75
V
-
2048
00
Bus-voltage
R
UINT
0-65535
-
V
-
2051
00
Motor running
direction
R/W
DINT
0-1
0
--
0: CCW direction
1: CW direction
But it is recommended to modify by
0x607E
2056
00
Alarm detection
selection
R/W/S
DINT
0~65535
65535
--
Bit setting:
=1: Yes; =0: No
Bit0: over-current (invalid)
Bit1: over-voltage
Bit2: Position following error
Bit3: Encoder wiring error
Bit4: over speed alarm
2057
00
Reset alarm
R/W/S
UINT
0~65535
0
--
Write value 1 to clear the alarm. But
it is recommended to write value
128(Decimal) to 0x6040
2090
01
Current loop Kp
R/W
DINT
0~32767
1500
--
--
02
Current loop Ki
R/W
DINT
0~32767
300
--
--
03
Current loop Kc
R/W
DINT
0~32767
300
--
--
2091
01
Speed Loop Kp
R/W
UINT
0~10000
25
-
