Leetro MPC6575 User Manual

MPC6575-Close-loop Laser Engraving &Cutting Controller (Rev. 1.0)
4
1 2 3 4 5 6
OUT1
Blow-off
On/Off
OUT2
Process
completion
indicator light
OUT3
USB stick
indicator
light
OUT4
General
output 3
OUT5
General
output 4
OUT6
Speed-zero clamp
output
Group 4: LASER (Laser Control Signal Pins)
1 2 3 4 5 6 7
GND DA1
Analog
Output1
DA2
Analog
Output 2
PWM+ PWM- STH+
Laser On/Off
Differential+
STH-
Laser On/Off
Differential+-
Group 5: Z-AXIS (Z-axis Step Motor Contrl Signal Pins)
1 2 3 4
Z_PUL
Z-axis pulse
Z_DIR
Z-axis direction
GND 5V
Group 6: Y-AXIS (Y-axis Servo Motor Control Signal Pins)
1 2 3 4
Y_DAC
Y-axis analog
output
GND
Analog GND
Y_EN
Y-axis servo enable output
Y_ALM
Y-axis servo alarm input
Group 7: X-AXIS (X-axis Servo Motor Control Signal Pins)
1 2 3 4
X_DAC
X-axis analog
output
GND
Analog GND
X_EN
X-axis servo enable output
X_ALM
X-axis servo alarm input
Group 8: Z-LIMIT (Z-axis Origin and Limit Signal Pins
）
1 2 3 4 5
Z_EL+ Z_EL- Z_ORG GND 24V
Group 9: Y-LIMIT
（Y-axis Origin and Limit Signal Pins）
1 2 3 4 5
Y_EL+ Y_EL- Y_ORG GND 24V
Group 10: X-LIMIT
（X-axis Origin and Limit Signal Pins）
1 2 3 4 5
X_EL+ X_EL- X_ORG GND 24V
Group 11: Y-ENCODER (Encoder feedback signal port for Y-axis）
1 2 3 4 5 6
Y_A+ Y_A- Y_B+ Y_B- Y_Z+ Y_Z-
Group 12: X-ENCODER (Encoder feedback signal port for X-axis
）
1 2 3 4 5 6
X_A+ X_A- X_B+ X_B- X_Z+ X_Z-
