4 Version 3.3
Operator’s Manual Functional Description
Functional Description
Receiver Configurations
This GPS receiver is available in six basic configurations, identified
by product description and part number. Refer to the Auxiliary Unit
Information section of the manual to view sample screens to
identify your particular model.
6 Channel GPS
The basic 6 channel GPS navigator is capable of receiving DGPS
corrections in the RTCM SC-104 version 2 format via one of the
four input data ports. However, it does not have an internal marine
beacon DGPS receiver. This model is supplied with a GPS only
Volute, Discus, or Globe style antenna. Should you decide at a later
date to upgrade your receiver to a GPS with Built-in Beacon, the
display unit must be returned to the factory to install the appropriate
components and software. In addition, a separate whip, loop
(optional), or combined (optional) antenna is supplied with the
upgrade. This model can be upgraded to a 12 channel GPS model in
the field, by purchasing a 6 channel baseband daughter board (P/N
10502).
6 Channel GPS With Built-in Beacon
This is a standard 6 channel DGPS navigator with an integrated
internal beacon receiver. It is capable of receiving DGPS correc-
tions in the RTCM SC-104 version 2 format via its internal marine
beacon DGPS receiver, or via one of the four input data ports. This
model is supplied with a GPS and Loop (H-Field) combined Discus
style antenna. A separate (optional) whip or loop antenna may be
used with this model; however, an additional internal cable must be
installed in this configuration. This model can be upgraded to a 12
channel GPS model in the field, by purchasing a 6 channel
baseband daughter board (P/N 10502).
12 Channel GPS
This is a 12 channel GPS upgraded version of the basic 6 channel
GPS navigator. It is capable of receiving DGPS corrections in the
RTCM SC-104 version 2 format via one of the four input data
