Version 3.3 5
Functional Description Operator’s Manual
ports. However, it does not have an internal marine beacon DGPS
receiver. This model is supplied with a GPS only Volute, Discus, or
Globe style antenna. Should you decide at a later date to upgrade
your 6 channel to a 12 channel receiver or your 12 channel receiver
to a 12 channel with built-in beacon, the display unit must be
returned to the factory to install the appropriate components and
software. In addition, a separate whip, loop (optional), or combined
(optional) antenna is supplied with this upgrade.
12 Channel GPS With Built-in Beacon
This is a 12 channel GPS upgraded version of the standard 6
channel with built-in beacon DGPS navigator. It is capable of
receiving DGPS corrections in the RTCM SC-104 version 2 format
via one of the four input data ports, or via its internal marine beacon
DGPS receiver. This model is supplied with a GPS and Loop (H-
Field) combined Discus style antenna. A separate (optional) whip or
loop antenna may be used with this model, however, an additional
internal cable must be installed in this configuration.
6 Channel Dual Control
This is an enhanced 6 channel DGPS navigator. Two GPS receivers
are actually supplied, one 6 channel GPS (operating as a slave unit)
and one 6 channel with built-in beacon (operating as a master unit)
with one GPS and Loop (H-Field) combined Discus style antenna.
It is capable of receiving DGPS corrections in the RTCM SC-104
version 2 format via one of the four input data ports, or via its
internal marine beacon DGPS receiver. This configuration allows
data to be shared between two remotely separated stations (i.e.
navigator’s station and helmsman’s station), with independent
access to various information fields. The 6 channel GPS unit gets its
positioning information from the 6 channel GPS with built-in
beacon unit, but can be connected to the antenna independently and
calculate its own position as a back-up GPS receiver. This model
can be upgraded to a 12 channel GPS model in the field, by
purchasing a 6 channel baseband daughter board (P/N 10502).
12 Channel Dual Control
This is a 12 channel GPS upgrade to the enhanced 6 Channel Dual
Control configuration. It is a dual head DGPS system where two
GPS receivers are actually supplied, one 6 channel GPS (operating
