5.4002.8501.0 B
Operating Instructions 5-23
Figure 35. Never make an angled start (>30 degrees)
5.11.1.2 Go Straight
When moving straight forward, the deviation can be more than 10%. Take this into
account when you set up a route. If possible, include a bump point after going straight.
Before starting, make sure the machine points in the correct direction. Use the Straight
option as little as possible. If it really is necessary, for example to get the machine
through a doorway, make the distance travelled as short as possible. Once through the
doorway, continue to follow a wall left or right, or Ultrasound L. This improves the
accuracy of the route that is travelled.
1. Select Straight and push
.
