5.4002.8501.0 B
Maintenance 6-5
2. Start the time path to put the machine into operation (see Start or Stop the Time Path on page 5-33).
6.3.3 Clean the Sensing Wheel
Do not use water to clean the sensing wheel!
Preparation
1. Manually drive the machine to a clean and quiet location (see Manually drive the Machine on page 5-
7).
Clean
Unexpected cow movement.
Risk of being crushed or trampled.
Block the cow traffic.
Heavy parts.
Risk of personal injury.
Use suitable lifting or tilting equipment.
1. Use a suitable lifting or tilting tool to lift the front of the machine and put the vehicle on its rear (see
figure 41 on page 6-6).
2. Remove the dirt between the sensing wheel and the nose with a brush.
3. Remove the dirt between the sensing wheel and the concrete block with a screw driver and a brush.
4. Make sure that the sensing wheel can turn freely.
5. Use a suitable lifting or tilting tool to put the machine back onto its wheels.
