4.1059.8506.0 A
6-12 Operating Instructions
2. Move the three-point hitch of the tractor upwards to lift the rake
from the ground.
3. Disengage the PTO.
4. Wait for all moving parts to stop.
5. When leaving the field:
1. Put the rake into the transport position (see page 6-3).
6.9 Take the Rake out of Operation
To work safely it is important to take the rake out of operation before
doing maintenance, troubleshooting, making adjustments or before
certain operations. After taking the rake out of operation the tractor and
the rake are standing stable, all parts have stopped and parts will not
move unexpectedly.
To take the rake out of operation:
1. Stop the tractor.
2. Engage the parking brake of the tractor.
3. Disengage the PTO.
4. Wait until all moving parts have stopped.
5. Switch off the tractor engine and remove the key.
6.10 Disconnect the Rake from the Tractor
Always put the rake on hard, even ground.
1. Take the rake out of operation (see page 6-12).
2. Put the parking jack (1) (see figure 23 on page 6-13) in the bottom
position.
3. Secure the steering device with the locking pin (2).
4. Use the tractor three-point hitch system to lower the headstock
until the parking jack rests on the ground.
5. Switch of the tractor engine and remove the key.
6. Disconnect the PTO shaft from the tractor PTO.
7. Put the PTO shaft in the hook (3).
8. If applicable, disconnect the lighting plug from the tractor socket.
9. Disconnect the top link from the headstock of the rake.
10. Disconnect the lower arms of the three-point hitch from the rake.
