LELY HIBISCUS 455 - Lubricate the Steering Device of the Headstock

4.1059.8506.0 A
Maintenance 8-7
Figure 33. Lubricate the height adjustment winding handle
KEY:
1. Grease nipple of the height adjustment winding handle
8.2.6 Lubricate the Steering Device of the Headstock
Requirements
1. Grease pump
2. Biodegradable grease (SEP2)
Procedure
1. Take the rake out of operation (see page 6-12).
2. Lubricate the grease nipples of the steering device.
