LELY HIBISCUS 455 - Lubricate the Lower Rotor Wheel Assembly

4.1059.8506.0 A
Maintenance 8-5
KEY:
1. Grease nipple of the gears - 2. Grease nipple of the bearing of the axis
8.2.4 Lubricate the Lower Rotor Wheel Assembly
Requirements
• Grease pump
• Biodegradable grease (SEP2)
Procedure
1. Take the rake out of operation (see page 6-12).
2. Lubricate the two grease nipples on the lower rotor wheel
assembly.
