Adjustment 7-1
7 ADJUSTMENT
Before you adjust the rake always:
1. Stop the tractor.
2. Engage the parking brake of the tractor.
3. Disengage the PTO.
4. Wait until all moving parts have stopped.
5. Switch off the tractor engine and remove the key.
7.1 Adjust the Swath Width
The adjustment depends on the amount of crop and the working width.
Select a position that allows the crop to flow between the rotor and the
swath curtain properly and that prevents the formation of lumps.
1. Take the rake out of operation (see page 6-12).
2. Slide the swath curtain (1) (see figure 24 on page 7-2) to the
required position and secure it with the locking pin (2).
