4.1059.8506.0 A
8-16 Maintenance
8.2.12 Make sure the Tyres have the correct Pressure
Make sure the rake is out of operation when you inflate the
tyres.
Do not over-inflate the tyres.
1. Make sure the tyres of the rotor wheels have a pressure of 2.75 bar
(40 Psi).
8.2.13 Clean the Rake
To avoid damage, do not spray water directly onto the electric system or
bearings. If you use a high pressure cleaner, keep a minimum spraying
distance of 30 cm (1 ft) to avoid damage to the paint.
1. Use a jet of water to thoroughly clean the rake.
2. Lubricate all bearings to push out any water.
8.3 Corrective Maintenance Procedures
8.3.1 Replace the Tine(s)
Procedure
1. Take the rake out of operation (see page 6-12).
2. Release the nut (5) (see figure 40 on page 8-17) and remove the
bolt (1) and clamp block (2) from the applicable tine(s).
3. Remove the cap (3).
4. Replace the broken tine(s) and slide all the tines on the tine arm in
the correct position.
5. Install the cap.
6. Install the bolt and clamp block on the tine position(s).
7. Tighten the nut(s) to secure the position of the tine(s).
