4.1059.8506.0 A
8-4 Maintenance
Figure 31. Lubricate the bearing block of the PTO extension
KEY:
1. Grease nipple of the PTO extension
8.2.3 Lubricate the Gearbox of the Rotor
Requirements
• Grease pump
• Biodegradable grease (SEP2)
Procedure
1. Take the rake out of operation (see page 6-12).
2. Lubricate the grease nipple of the rotor gears (1) with the grease
pump. While lubricating, turn the rotor bit by bit to make sure
grease is distributed effectively over the gears.
3. Lubricate the grease nipple of the bearing of the axis (2).
