4.1059.8506.0 A
8-12 Maintenance
Skip the next three pairs of nuts (in this example the pair of nuts with
numbers 2,3, and 4).
Then tighten the next pair of nuts (in this example the pair of nuts with
number 5).
4. Repeat this until all 22 nuts are torque tightened (so the tightening
order is 1, 5, 9, 2, 6, 10, 3, 7, 11, 4, 8)
Figure 37. Torque tighten the bolts and nuts of the rotor
