LEMKEN Diamant 11 - 11.4 Damper on land wheel

Operation
70
11.4 Damper on land wheel
During in-furrow ploughing in the field, the
damper (1) does not function, as the
bracket (2) is resting on the pin (3) for
depth limitation.
When travelling on the headland and on
the road, the pin (3) for depth limitation
must be able to move freely.
−
Adjust the pin (3) to create free space of
at least 3 cm to ensure that there is suf-
ficient room for spring deflection.
1
3
2
