LEMKEN Diamant 11 - 12.16.2 Working depth

Adjustments
95
12.16.2 Working depth
Rigid disc coulter
The working depth of the disc coulter is ad-
justed as follows:
− Undo the screw (2).
− Swivel coulter arm (1) as required.
Spring-loaded disc coulter (version T)
Ensure that the teeth on
the coult
er arm (1) mesh
exactly with the adjacent
tooth
ed bracket (3) before
tightening the screw (2).
1
2
3
1
2
1
2
!
