Adjustments
83
All plough bodies must be adjusted to the
same pitch angle.
−
Adjust pitch angle of the first and last
plough body.
− Measure distance betwee
plough frame (= reference dimension)
− Adjust the remaining plough bodies ac-
cording to this reference dimension.
Adjustment tip:
rear point
s and sight the
height of the remaining
points.
− Finally, retighten all screws. See
«Tightening torques, page 122».
