Table 1. Home Screen Display
Number Display Item Description
1 ON/OFF button Tap to turn the indoor unit on or o󰀨.
2 Settings button Tap to access the menu screen.
3 Time Display Displays the current system time.
4 Auto Mode Settings
Select Auto mode when the indoor unit is ON, and then
the indoor unit will run in Auto mode (the icon illuminates
after selection).
5 Cooling Mode Settings
Select Cooling mode when the indoor unit is ON, and
then the indoor unit will run in Cooling mode (the icon
illuminates after selection).
6 Heating Mode Settings
Select Heating mode when the indoor unit is ON, and
then the indoor unit will run in Heating mode (the icon
illuminates after selection).
7 Dry Mode Settings
Select Dry mode when the indoor unit is ON, and then the
indoor unit will run in Dry mode (the icon illuminates after
selection).
8 Fan Mode Settings
Select Fan mode when the indoor unit is ON, and then the
indoor unit will run in Fan mode (the icon illuminates after
selection).
9
Temperature Unit Set-
tings
Switch the temperature unit: display in
Fahrenheit/Celsius temperature.
10 Operation Mode Displays the mode of operation of the indoor unit.
11
Fan Speed Control
Button
Select fan speed, and tap “Auto”, “High”, “Med”, or “Low”
to conrm the selection.
12
Indoor Temperature
and Humidity Display
Display the temperature and humidity of the room in
which the indoor unit is located.
13 Setpoint Displays the setpoint.
14
Setpoint Adjustment
Slider
Adjust the setpoint by pressing and sliding.
15
Vertical Swing Angle
Display
Displays the vertical swing angle of the indoor unit; tap to
access the vertical swing angle settings.
16
Horizontal Swing Posi-
tion Display
Display the horizontal swing angle of the indoor unit; tap
to enter the horizontal swing angle settings.
17
Weekly Schedule
Display
Display the setting status of the weekly schedule status,
and tap to access the weekly.
18
Override Status
Display
Display the Override status and tap here to set the
Override settings.
