9 Technical data and accessories Lenord+BauerTechnical data GEL 2444
68 GEL 2444
English
9 Technical data and accessories
9.1 Technical data GEL 2444
GEL
2444
3
GEL
2444 5
Target wheel
Module
(1)
0.3 0.5
Width of the signal track ≥ 4.0 mm
Material Ferromagnetic steel
Reference mark Slot (M), lug (N), tooth (Z)
Geometric data
Centre distance between sensor elements (1/2
and N) c
2
6 mm
Distance mounting surface to sensor element
(1/2) c
1
9.5 mm
Air gap permitted 0.15 mm
± 0.02 mm
0.20 mm
± 0.03 mm
Electrical data
Supply voltage U
B
5 V DC ± 5%, polarity reversal protected,
overvoltage protected
Output signal level
GEL 2444D TTL / RS422
GEL 2444K 1 V
pp
Differential signal
GEL 2444T TTL / RS422
Output signal
GEL 2444D Two square-wave signals offset by 90°
and their inverse signals, short-circuit-
proof; option: reference signal
GEL 2444K Two sinusoidal signals offset by 90° and
their inverse signals, short-circuit-proof;
option: reference signal
GEL 2444T Two square-wave signals offset by 90°
and their inverse signals, short-circuit-
proof; option: reference signal
Output frequency
GEL 2444D 0…500 kHz
(2)
GEL 2444K 0…200 kHz
(2)
GEL 2444T 0…500 kHz
(2)
Power consumption without load ≤ 0.3 W
(1)
Further modules upon request
(2)
At a cable capacitance of 5 nF
