4.Toinstallanewharddiskdriveintothebluebracket,flexthebracketandalignpin1,pin2,pin3,
andpin4onthebracketwiththecorrespondingholesintheharddiskdrive.Donottouchthecircuit
board5onthebottomoftheharddiskdrive.
Figure53.Installingtheharddiskdriveintothebracket
5.Slidethenewharddiskdriveintotheenclosurefromtherearuntilitsnapsintoposition.
Figure54.Installingtheharddiskdriveintotheenclosure
Chapter7.Installingorreplacinghardware81
