Mechanical installation
Mounting in cold−plate design
4
112
EDK82EV222 DE/EN/FR 13.0
Mounting
Note!
ƒ Apply the heat−conducting paste onto cooler and cooling plate before you bolt the
controller onto the cooler to reduce the heat transfer resistance to its minimum.
ƒ The heat−conducting paste supplied in the accessory kit will do for
approx. 1000 cm
2
.
1. Insert fixing rails into the cooling plate from above and below
2. Clean the contact surfaces of cooler and cooling plate with methylated spirit.
3. Use a spatula to apply a thin layer of heat−conducting paste.
4. Bolt the controller tightly together with the cooler using two screws.
