Lenze E82EV User Manual

Commissioning
Important codes for quick commissioning
7

148
EDK82EV222 DE/EN/FR 13.0
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0002
*
!
uSEr
(Continu
ation)
Loading/copyin
g the own basic
setting
By using this function you can also
just copy PAR1 into the parameter
sets PAR2 ... PAR4
5 own basic setting ð PAR1 Restore own basic setting in the
parameter set selected
6 own basic setting ð PAR2
7 own basic setting ð PAR3
8 own basic setting ð PAR4
C0003
*

Saving
parameters
non−volatilely
1 0 Do not save parameters in the EEPROM Data loss after mains switch−off
1 Always save parameters in the EEPROM l Active after every mains
connection
l Cyclic alteration of parameters
via bus module is not permissible
3 Save your own basic setting in the
EEPROM
Afterwards save parameter set 1 as
own basic setting with C0002 = 9
C0007

uSEr
Fixed
configuration
digital inputs
Change of C0007 is copied into the
corresponding subcode of C0410.
Free configuration in C0410 sets
C0007 = 255!
0 E4 E3 E2 E1 l CW/CCW = clockwise
rotation/counter−clockwise
rotation
l DCB = DC injection brake
l QSP = quickstop
l PAR = change over parameter set
(PAR1 ó PAR2)
– PAR1 = LOW, PAR2 = HIGH
– The terminal in PAR1 and
PAR2 has to be assigned
with the "PAR" function.
– Only use configurations
with "PAR" if C0988 = 0
l TRIP−Set = external error
0
CW/CCW DCB JOG2/3 JOG1/3
1
CW/CCW PAR JOG2/3 JOG1/3
2
CW/CCW QSP JOG2/3 JOG1/3
3
CW/CCW PAR DCB JOG1/3
4
CW/CCW QSP PAR JOG1/3
5
CW/CCW DCB TRIP−Set JOG1/3
6
CW/CCW PAR TRIP−Set JOG1/3
7
CW/CCW PAR DCB TRIP−Set
8
CW/CCW QSP PAR TRIP−Set
9
CW/CCW QSP TRIP−Set JOG1/3
10
CW/CCW TRIP−Set UP DOWN
C0007

uSEr
(Continu
ation)
E4 E3 E2 E1 l Selection of fixed
setpoints
JOG1/3 JOG2/3
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
Active
C0046
JOG1
JOG2
JOG3
11
CW/CCW DCB UP DOWN
12
CW/CCW PAR UP DOWN
13
CW/CCW QSP UP DOWN
14
CCW/QSP CW/QSP DCB JOG1/3
15
CCW/QSP CW/QSP PAR JOG1/3
16
CCW/QSP CW/QSP JOG2/3 JOG1/3
17
CCW/QSP CW/QSP PAR DCB
18
CCW/QSP CW/QSP PAR TRIP−Set
19
CCW/QSP CW/QSP DCB TRIP−Set
