Lenze E82EV User Manual

Commissioning
Important codes for quick commissioning
7

147
EDK82EV222 DE/EN/FR 13.0
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0002
*
!
uSEr
(Cont.)
Transferring
parameter sets
with the keypad
Keypad ð PAR1 (+ FPAR1) Overwrite selected parameter set
and, if required FPAR1, with the
corresponding data of the keypad
71 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
11 with all other function modules
Keypad ð PAR2 (+ FPAR1)
72 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
12 with all other function modules
Keypad ð PAR3 (+ FPAR1)
73 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
13 with all other function modules
Keypad ð PAR4 (+ FPAR1)
74 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
14 with all other function modules
Controller ð keypad Copy all available parameter sets
(PAR1 ... PAR4, if required FPAR1) into
the keypad
80 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
20 with all other function modules
Keypad ð function module Only overwrite the module−specific
parameter set FPAR1 with the data of
the keypad
40 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
Function module ð keypad Only copy the module−specific
parameter set FPAR1 into the keypad
50 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
C0002
*
!
uSEr
(Continu
ation)
Saving your
own basic
setting
9 PAR1 ð own basic setting For the parameters of the controller
you can save an own basic setting
(e.g. the delivery status of your
machine):
1. Ensure that parameter set 1 is
active
2. Inhibit controller
3. Set C0003 = 3, confirm with 
4. Set C0002 = 9, confirm with ,
the own basic setting is saved
5. Set C0003 = 1, confirm with 
6. Enable the controller
