Operation
Calling up information messages
6

61
EDBPM−H310 DE/EN/FR 7.1
6.3 Calling up information messages
ƒ Information messages
– are texts which can be indicated after a certain event (e.g. if an actual
value exceeds a limit).
– can only be called up as long as the triggering event is active.
– must be programmed in the »HMI Designer« planning tool.
– can have a maximum length of 2 lines × 20 characters.
ƒ The operating unit does not indicate whether an information message is
available or not.
If you want to ... Press keys ... Example
A call up an information message.
shift
+
Info
â
Pressure exceeds
safety limit
B select the previous or next information
message.
Help
á
or
Info
â
Water level below
working treshold
C close the information message.
F1
Esc
6.4 Calling up help messages
ƒ Help messages
– can be assigned to page or information messages.
– contain useful notes to make handling easier.
– must be programmed in the »HMI Designer« planning tool.
ƒ The operating unit does not indicate whether a help message is available
for a page or an information message.
If you want to ... Press keys ... Example
A call up a help message.
shift
+
Help
á
B close a help message.
F1
Esc
