Lenze EPM-H310 - Electrical Data

Technical data
Electrical data
2

44
EDBPM−H310 DE/EN/FR 7.1
2.2 Electrical data
Field Values
Display
Type LCD
Display format Text
Visible size 73.5 × 11.5 mm
Lines × Characters 2 × 20
Character size 3.2 × 5.5 mm
Character size in text mode 5 × 7 pixels
Fonts ASCII, Katakana
Contrast setting Trimming potentiometer
Background illumination LED
Electrical
connection
DC voltage supply +18 ... 32 VDC
Power consumption 5 W at 24 VDC
Fusing Micro−fuse Æ5 × 20 mm, 315 mA / F
Network:
System bus (CAN)
Protocol System bus (CAN)
Network topology Line (terminated at both ends with 120 W)
System bus station Master or slave
Max. number of stations 63
Baud rate [kbit/s] 20 50 125 250 500 1000
Max. bus length [m] 2500 1000 500 250 80 25
Memory User program 48 kb
Interfaces
Serial
ASP8 (8−pole minidin
socket)
RS232
