9300 Servo PLC
System blocks
2.5 ANALOG1_IO
2-17
L
ServoPLC EN 2.0
2.5.2 Outputs_ANALOG1
Analog output 1 (module number: 11)
You can use this SB as a monitor output. Internal analog signals can be output via terminal X6/62 as
voltage signals, and used, for example, as display or setpoints for following drives.
Outputs_ANALOG1
AOUT1_nOut_a
C0434/1
X6
62
Fig. 2-9 Outputs_ANALOG1
VariableName
DataType SignalType Address DIS DIS format Note
AOUT1_nOut_a Integer analog %QW11.0 C0434/1 dec [%] Analog output 1
Terminal assignment
Terminal Use Data
X6/62 Analog output 1 (monitor 1) Level:
Resolution:
Normalisation:
-10V...+10V(max.2mA)
20 mV (9 bit + sign)
±10 V ≡±16384 ≡±100 %
X6/7 Internal ground, GND -
