Appendix A
Specifications
Wireless Access Point
Hardware Specifications
CPU
Atheros AR9132
Radio-on-Chip
Atheros AR9103
DRAM
32 Mbytes (can be expanded to 64 Mbytes)
Flash ROM
8 Mbytes
LAN port
1 x Auto-MDIX RJ 45 for 10/100Mbps PoE port
IEEE 802.3af compliance
11b
Embedded Atheros solution
Network Standard IEEE 802.11b (Wi-Fi™) and
IEEE 802.11g compliance
OFDM; 802.11b: CCK (11 Mbps, 5.5 Mbps),
DQPSK (2 Mbps), DBPSK (1 Mbps)
Operating Frequencies 2.412.2.497 GHz
Operating Channels 802.11g: 11 for North America,
13 for Europe (ETSI), 14 for Japan
802.11b: 11 for North America, 14 for Japan, 13 for
Europe (ETSI)
11n
IEEE802.11n compliant
Rx Sensitivity: 11.n: 300Mbps@ -69dBm, 11.g:
54Mbps@ -73dBm, 11.b: 11Mbps@ -88dBm
Antennae
3 x 2dbi detachable antenna
Operating temperature
0 C to 40 C
Storage temperature
-20 C to 70 C
Power Adapter
12VDC 1A External
Dimensions
165mm(W) * 153mm(D) * 33mm(H)
