User Guide
Leviton MLC 16D Motorized Lighting Controller Page 31 of 62
62
MIDI
The MLC 16 allows you to use MIDI commands to activate and deactivate the
playback of scenes, patterns, and shows.
Setting the MIDI Channel
All MIDI commands sent and received by the MLC 16D use this channel number.
It can be set from 1 to 16.
To set the MIDI channel:
1
Press the Edit button.
2
Press F4, above Setup.
3
Press F3, above Console.
4
Press the More button two times.
5
Press F4, above Select Edit.
6
Turn Modify wheel 2 to select the desired MIDI channel.
7
Press F4, above Select Save.
8
Press the Blackout or Edit button to exit Setup mode.
Default MIDI Assignments
The default MIDI assignment sends a two command sequence whenever a scene,
pattern, or show is deactivated. In the following table, ranges of values are
indicated between brackets: { }.
Effect Command 1 Command 2
Scene {1...24} On Program 64 Program {0...23}
Pattern {1...24} On Program 65 Program {0...23}
Pattern {25...48} On Program 66 Program {0...23}
Pattern {49...72} On Program 67 Program {0...23}
Pattern {73...96} On Program 68 Program {0...23}
Show {1...24} On Program 69 Program {0...23}
Scene {1...24} Off Program 70 Program {0...23}
Pattern {1...24} Off Program 71 Program {0...23}
Pattern {25...48} Off Program 72 Program {0...23}
Pattern {49...72} Off Program 73 Program {0...23}
Pattern {73...96} Off Program 74 Program {0...23}
Show {1...24} Off Program 75 Program {0...23}
Blackout Program 114 None
