Device Assignment Formats
Keyword Valid Values Description
FixAssign 1-16 followed by a device
name, comma and
channel offset
Assigns devices to Fixture
buttons.
Group 1-4 Establishes Group number for
group assigning.
GroupFix 1-16 Defines a Fixture button to a
group.
MaxDims 49-512 Maximum number of dimmers
output.
InterB 0-256 DMX512 interbyte delay.
DMX IM Mod Off, PassThru, 9 channel DMX512 Input mode.
DMX In Ch 1-504 Starting channel for 9 channel
DMX512 Input.
Rlock Yes, No Record lock.
Slock Yes, No Setup lock.
Flock Yes, No Fixture lock.
MidiCh 1-16 MIDI channel.
MidiScn 1-24 Establishes Scene number for MIDI
command assigning.
MidiPat 1-96 Establishes Pattern number for
MIDI command assigning.
MidiShw 1-24 Establishes Scene number for MIDI
command assigning.
