User Guide
Page 60 of 62 Leviton MLC 16D Motorized Lighting Controller
62
Specifications
Console Specifications
Control Channels 512 (Up to 512 DMX512, In/Out)
Maximum fixtures 16
Maximum groups 4
Memory scenes 24
Patterns 96 (Each with up to 16,923 scene steps or 808 full
steps)
Shows 24 (Each with up to 24 steps each)
Memory Non-volatile FEPROM (at least 10 year retention)
MIDI In/Out/Thru
Disk Drive 3 1/2” MSDOS compatible 1.44 MByte HD only
Input Power 85-135 Volts AC; 185-250 Volts AC; 50-60 Hz
Input Power Fuses 250 VAC, 800 MA
Approx. Dimensions
(H x W x D)
4" x 24" x 15"
Weight (lbs) 12
