User Guide
Page 46 of 62 Leviton MLC 16D Motorized Lighting Controller
62
Show Formats
Following is an example of a Show file in ASCII format. This Show has four steps
and will loop through them ten times. Step 1 runs Pattern 1 four times, step 2
runs Pattern 2 five times, step 3 runs Pattern 80 two hundred times and step 4
runs Pattern 20 ten times.
Pattern 1
Loop 10
Step 1
PatNum 1
Times 4
Step 2
PatNum 2
Times 5
Step 3
PatNum 80
Times 200
Step 4
PatNum 20
Times 10
Keyword Valid Values Description
Show 1-24 Establishes Pattern number to be programmed.
Loop 1-250, Infinite Determines the number of times the show will
loop until it extinguishes itself.
Step 1-24 Establishes Step number to be programmed.
PatNum 1-96 Determines the Pattern number that will run
during a show step.
Times 1-250 Determines the number of times the pattern
will loop within the show step.
