Parts catalog 7-13
2580+, 2581+, 2590+, 2591+
Assembly 5: ASF—Roller/support
Asm-
Index
Part
number
Description
5-1 40X2888 Roller, ASF upper feed (2580, 2590)
1 40X3023 Roller, ASF upper feed (2581, 2591)
2 40X2889 Roller, ASF lower feed (2580, 2590)
3 40X2984 Roller, ASF pick-up left and right (2580, 2590)
4 40X2985 Roller, ASF pick-up left and right (2581, 2591)
4 40X2927 Support, ASF paper right
5 40X2928 Support, ASF paper left
6 40X2891 ASF springs, parts packet
7 40X3136 ASF gears and bushings, parts packet
