Lexmark Forms Printer 4227 Plus - Page 44

Chapter 3: Using the Operator Panel
38
Using the Operator Panel
AutoGap
If “Enable” is selected in
“Default Macro”, this item
appears in the macro menu.
On
– Automatically adjusts the printer to
the thickness of the paper being
printed upon.
– Select this option when you want
the printer to check for paper
thickness every time paper is
loaded.
—
Off
– Allows you to manually specify the
thickness of the paper being printed
upon.
– Select this option when you want to
specify how thick the paper is.
Manual Position:
1, 2, 3, 4, 5, 6, 7
Single
– Adjusts the printhead to the paper
thickness:
• when you turn the printer on,
• when you change the paper select
lever.
– Select this option when you want to
print several cut sheets with the
same paper thickness when using
the Auto Sheet Feeder.
Open, Fixed
Main Menu Primary Options Secondary Options
