Lexmark S400 Series - INA Card Removal

Repair information 4-13
Lexmark S400 Series
INA card removal
1. Remove the ADF/scanner assembly. See “ADF/scanner assembly removal” on page 4-3.
2. Remove the midframe. See “Midframe removal” on page 4-11.
3. Remove the screw (A) from the midframe cover.
4. Lift the INA card shield, and disconnect the cable (B) from the INA card.
A
B
