4-18 Service Manual
Lexmark S400 Series
Operator panel removal
1. Remove the ADF/scanner assembly. See “ADF/scanner assembly removal” on page 4-3.
2. Remove the midframe. See “Midframe removal” on page 4-11.
3. Disconnect the cable (A).
4. Lift the operator panel, and remove.
A
