Lexmark S400 Series - Media Sensor Removal

4-40 Service Manual
Lexmark S400 Series
Media sensor removal
1. Remove the ADF/scanner assembly. See “ADF/scanner assembly removal” on page 4-3.
2. Remove the midframe. See “Midframe removal” on page 4-11.
3. Remove the two screws (A).
4. Disconnect the cable (B).
A
B
