Lexmark S400 Series Service Manual

Repair information 4-27
Lexmark S400 Series
RFID card removal
1. Remove the ADF/scanner assembly. See “ADF/scanner assembly removal” on page 4-3.
2. Remove the midframe. See “Midframe removal” on page 4-11.
3. Remove the two screws (A), and disconnect the cable (B).
4. Remove the RFID card.
A B
