Lexmark S400 Series Service Manual

5-4 Service Manual
Lexmark S400 Series
J2 Transport carrier motor Red, black 1 & 2 30 V
J3 Purge pump motor Red, yellow 1 & 2 30 V
J4 Power supply Blue, black 1 & 2 30 V
J5 Scanner motor Green, white, red, blue
J6 ADF paper feed motor Orange, yellow, brown,
black
J8 ADF EOF Red, black, black, black 1 & 2 3 V
J11 Not used
J12 Wireless INA card
J14 Control panel
J15 Fax card
J16 USB
J18 Card reader
J20 PictBridge
J21 Carrier
J22 Carrier
J23 Carrier
J24 CIS
J25 Encoder dial sensor
J26 EOF
J28 Paper feed encoder dial
J31 RFID card
BT1 Battery
PS1 Ink tank access sensor
