EXTERNAL EQUIPMENT SETUP
14
EXTERNAL EQUIPMENT SETUP
VCR SETUP
When connecting with an antenna
■ To avoid picture noise (interference), leave an adequate distance between the VCR and TV.
■ If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the screen.
This phenomenon is common to all manufactures and in consequence the manufactures warranty does not cover
the product bearing this phenomenon.
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Wall Jack
Antenna
1
2
Connect the antenna cable to the RF
antenna in socket of the VCR.
Connect the RF antenna out socket of the
VCR to the AANNTTEENNNNAA//CCAABBLLEE socket on
the set.
1. How to connect
■ Set VCR output switch to 3 or 4 and then tune
TV to the same channel number.
■ Insert a video tape into the VCR and press PLAY
on the VCR. (Refer to the VCR owner’s manual.)
2. How to use
