Fig. 9 --- Refrigeration connections --- Collegamenti frigoriferi
Hmax=3m
Hmax=3m
F i g . 1 0 --- C o n d e n s a t e d r a i n --- S c a r i c o c o n d e n s a
NOTE:
FILL THE DRAIN TRAP WITH WATER BEFORE STARTING UNIT
NOTA:
RIEMPIRE IL SIFONE CON ACQUA PRIMA DI AVVIARE L’IMPIANTO
>30mm
