11. Appendix UCX series – User's Manual 100
Factory EDID List
Mem. Resolution Type
F1 640 x 480 @ 60.00 Hz D
F2 848 x 480 @ 60.00 Hz D
F3 800 x 600 @ 60.32 Hz D
F4 1024 x 768 @ 60.00 Hz D
F5 1280 x 768 @ 50.00 Hz D
F6 1280 x 768 @ 59.94 Hz D
F7 1280 x 768 @ 75.00 Hz D
F8 1360 x 768 @ 60.02 Hz D
F9 1280 x 1024 @ 50.00 Hz D
F10 1280 x 1024 @ 60.02 Hz D
F11 1280 x 1024 @ 75.02 Hz D
F12 1400 x 1050 @ 50.00 Hz D
F13 1400 x 1050 @ 60.00 Hz D
F14 1400 x 1050 @ 75.00 Hz D
F15 1680 x 1050 @ 60.00 Hz D
F16 1920 x 1080 @ 50.00 Hz D
F17 1920 x 1080 @ 60.00 Hz D
F18 2048 x 1080 @ 50.00 Hz D
F19 2048 x 1080 @ 60.00 Hz D
F20 1600 x 1200 @ 50.00 Hz D
F21 1600 x 1200 @ 60.00 Hz D
F22 1920 x 1200 @ 50.00 Hz D
F23 1920 x 1200 @ 59.56 Hz D
F24 2048 x 1200 @ 59.96 Hz D
F29 Universal DVI
F30 1440 x 480 @ 60.05 Hz H
F31 1440 x 576 @ 50.08 Hz H
F32 640 x 480 @ 59.95 Hz H
F33 720 x 480 @ 59.94 Hz H
F34 720 x 576 @ 50.00 Hz H
Mem. Resolution Type
F35 1280 x 720 @ 50.00 Hz H
F36 1280 x 720 @ 60.00 Hz H
F37 1920 x 1080 @ 50.04 Hz H
F38 1920 x 1080 @ 50.00 Hz H
F39 1920 x 1080 @ 60.05 Hz H
F40 1920 x 1080 @ 60.05 Hz H
F41 1920 x 1080 @ 24.00 Hz H
F42 1920 x 1080 @ 25.00 Hz H
F43 1920 x 1080 @ 30.00 Hz H
F44 1920 x 1080 @ 50.00 Hz H
F45 1920 x 1080 @ 60.00 Hz H
F46 1920 x 1080 @ 60.00 Hz H
F47 Universal HDMI with PCM audio
F48 Universal HDMI with All audio
F49 Universal HDMI, all audio, deep color
F91 1024 x 2400 @ 60.01 Hz H
F98 1280 x 720 @ 60.00 Hz H
F99 1920 x 1080 @ 60.00 Hz H
F100 1024 x 768 @ 60.00 Hz H
F101 1280 x 1024 @ 50.00 Hz H
F102 1280 x 1024 @ 60.02 Hz H
F103 1280 x 1024 @ 75.02 Hz H
F104 1600 x 1200 @ 50.00 Hz H
F105 1600 x 1200 @ 60.00 Hz H
F106 1920 x 1200 @ 59.56 Hz H
F107 2560 x 1440 @ 59.95 Hz H
F108 2560 x 1600 @ 59.86 Hz H
F109 3840 x 2400 @ 24.00 Hz H
F110 3840 x 2160 @ 24.00 Hz H
F111 3840 x 2160 @ 25.00 Hz H
Mem. Resolution Type
F112 3840 x 2160 @ 30.00 Hz H
F118 Universal HDMI, 4K, PCM audio
F119 Universal HDMI, 4K, all audio
F120 3840 x 2160 @ 60.00 Hz H
F121 1440 x 1080 @ 59.91 Hz H
F122 2560 x 2048 @ 59.98 Hz H
F123 1280 x 800 @ 59.91 Hz H
F124 1440 x 900 @ 59.90 Hz H
F125 1366 x 768 @ 60.00 Hz H
F126 1600 x 900 @ 59.98 Hz H
F127 2048 x 1080 @ 60.00 Hz H
F128 2560 x 1080 @ 60.00 Hz H
F129 3440 x 1440 @ 24.99 Hz H
F130 3440 x 1440 @ 29.99 Hz H
F131 4096 x 2160 @ 25.00 Hz H
F132 4096 x 2160 @ 30.00 Hz H
F133 4096 x 2160 @ 60.00 Hz 4:2:0
F134 3440 x 1440 @ 23.99 Hz H
F135 4096 x 2160 @ 24.00 Hz H
F136 3840 x 2400 @ 29.99 Hz H
F137 3840 x 2160 @ 60.00 Hz H2
F138 3840 x 2160 @ 50.00 Hz H2
F139 Universal HDMI 2.0, UHD, PCM audio
F140 Universal HDMI 2.0, UHD, all audio
F141 4096 x 2160 @ 60.00 Hz 4:4:4
F142 4096 x 2160 @ 50.00 Hz 4:4:4
F143 Universal HDMI 2.0, 4K, PCM audio
F144 Universal HDMI 2.0, 4K, all audio
F146 3840 x 2160 @ 60.00 Hz HDR
F147 3840 x 2160 @ 60.00 Hz RB, PCM
Mem. Resolution Type
F148 3840 x 2160 @ 60.00 Hz RB, ALL
U: Universal EDID, supporting many standard
resolutions:
▪ F29:
support).
▪ F47: HDMI EDID supporting PCM audio.
▪ F48: HDMI EDID supporting all type of audio.
▪ F49: HDMI EDID supporting all type of audio
and deep color.
▪ F89: Universal EDID for analog signals (no
audio support).
▪ F118: HDMI EDID supporting PCM audio and
4K@30 Hz signals.
▪ F119: HDMI EDID supporting all type of audio
and 4K@30 Hz signals.
Please note that minor changes in the factory EDID
