 UCX series – User's Manual 76

EDID Management

Command and Response #edid
ç 
æ pr·<source>:E1;<source>:E2; <source>:E3;<source>:E4
Parameters
Parameter Parameter description  
<source> Source EDID memory place
F1-F120
Factory EDIDs
U1-U14
User EDIDs
D1-D2
Dynamic EDIDs
Example
ç 
æ 
Emulated EDID memory for input port is listed with the EDID number that is currently emulated on the input.

Command and Response
ç 
æ pr·<validity>
Parameters
If the <validity> parameter is true, the EDID is valid. If the parameter is false, the EDID is invalid.
Example
ç 
æ 


Command and Response
ç <user_edid>.PreferredResolution
æ pr·<user_edid>.PreferredResolution=<preferred_resolution>
Example
ç 
æ 
INFO: Use the Manufacturer and MonitorName properties to query further information.
Emulating an EDID to an Input Port
Command and Response
ç <source>:<destination>)
æ mO·
Parameters
Parameter Parameter description  
<source> Source EDID memory place
F1-F120
Factory EDIDs
U1-U14
User EDIDs
D1-D2
Dynamic EDIDs
<destination> The emulated EDID memory of the desired input port
U1-U14
User EDIDs
Example
ç 
æ 
Emulating an EDID to All Input Ports
Command and Response
ç <source>)
æ mO·
Parameters
Parameter Parameter description  
<source> Source EDID memory place
F1-F148
Factory EDIDs
U1-U100
User EDIDs
D1-D2
Dynamic EDIDs
Example
ç 
æ 
