Lightware UCX Series User Manual

11. Appendix UCX series – User's Manual 104

Factory Default Settings
Parameter Setting/Value
Network settings
Factory default IP DHCP
Video crosspoint settings
O1 (HDMI out 1) I1
O2 (HDMI out 2) I3
Audio crosspoint settings
O3 (Analog out) I1
USB crosspoint settings
H1 (USB hub) U1 (USB-C Host 1)
Video port settings
 true
 false
 I1, I2: HDCP 1.4; I3,I4: HDCP 2.2
DP Alternate Mode Policy Auto
Autoselect operation policy Disable autoselect
Signal type Auto
HDCP mode Auto
 On
Emulated EDID on all four inputs Factory #47: Universal HDMI PCM
Analog audio output port settings
 0.00 dB (100%)
Balance 0 (center)
Autoselect Follow video O1
USB port settings
 Equal output power
DP Alternate Mode Policy Auto
Port Power Role Dual Role
Autoselect Follow video O1
 Auto
GPIO port settings
Output level High
Direction Input
Occupancy sensor
Sensor type Active high
Miscellaneous
Unique port names Cleared
Unique device label Cleared
User EDIDs Cleared
Applied Ports (Network Settings)

device and the softwares:
Purpose/function Protocol Port nr.
Firmware upgrade TFTP
UDP 69
UDP 49990
UDP 49995
Device Discovery UDP 224.0.0.251:5353
Remote IP UDP 230.76.87.82:37421




