11. Appendix UCX series – User's Manual 99
GPIO port #new
Connector type ................................................................8-pole Phoenix
Function (pin 1-6) .......................................
Function (pin 7) .......................................................................
Function (pin 8) ............................................................................Ground
OCS port #new
Connector type ........3-pole Reversed Gender Plug Phoenix connector
................................................................1
Port direction................................................................................... Input
USB port
Connector type ............................................................C-type receptacle
USB compliance ................................................................USB 3.1 Gen1
Connector type ............................................................A-type receptacle
USB compliance .................................................USB 2.0, USB 3.1 Gen1
Connector type ............................................................ B-type receptacle
USB compliance .......................................................................... USB 3.0
Connector type ...................................................................... mini-B type
USB compliance .......................................................................... USB 2.0
Port Numbering
Audio/Video Ports
Port name
Video port nr.
(LW3)
Audio port nr.
(LW3)
Inputs
USB-C in 1 I1 I1
USB-C in 2 I2 I2
HDMI in 3 I3 I3
HDMI in 4 I4 I4
I5 -
Outputs
HDMI out 1 O1 O1
HDMI out 2 O2 O2
Analog audio out - O3
USB Ports
Port name
USB port nr.
(LW3)
Upstream
Facing Ports
USB-C Host 1 U1
USB-C Host 2 U2
USB-B Host 3 U3
USB-B Host 4 U4
Downstream Port
USB hub H1
USB Device 1 D1
USB Device 2 D2
USB Device 3 D3
USB Device 4 D4
Ethernet Ports
Port name
USB port nr.
(LW3)
Secure Eth 1 P1
Utility Eth 2 P2
Utility Eth 3 P3
USB-C in1 (Eth) P4
USB-C in2 (Eth) P5
